APIE KR165C Hydraulic Bore Pile Hole Auger Rotary Big Diameter Drilling Rig: Versatile and Efficient
Product Overview:
1. Serialized Products: The APIE KR165C drilling rig offers different models and capabilities, providing multiple choices to meet the unique requirements of various customers. This ensures that you can find the right rig for your specific drilling needs.
2. Flexible Power Head: The power head of the drilling rig can be mechanically or hydraulically shifted, allowing for various drilling methods such as down-the-hole hammer, heel pipe, full casing, and alloy rotation. This versatility ensures adaptability to different drilling scenarios.
3. Enhanced Efficiency: The drilling rig features a hydraulic clamping shackle device and an automatic shackle, reducing auxiliary time and labor intensity. These features streamline the drilling process, improving overall efficiency.
4. Convenient Crawler Chassis: Equipped with a turning device, the crawler chassis enables the drilling rig to move and locate holes more conveniently and quickly. This feature enhances maneuverability and saves time during setup and repositioning.
| Performance Parameter | Unit | Value |
| Max. torque | kN.m | 165 |
| Max. drilling diameter | mm | 1500 |
| Max. drilling depth | m | 58/46 |
| Working speed | rpm | 7~28 |
| Max. cylinder pressure | kN | 155 |
| Max. hoist capacity | kN | 160 |
| Main winch pull force | kN | 160 |
| Main winch speed | m/min | 80 |
| Auxiliary winch pull force | kN | 60 |
| Auxiliary winch speed | m/min | 70 |
| Max. cylinder stroke | mm | 4200 |
| Mast side raking | ° | ±3 |
| Mast raking forward | ° | 5 |
| System pressure | mpa | 35 |
| Pilot pressure | mpa | 4 |
| Max. walking speed | km/h | 3 |
| Max. pull force | kN | 240 |
| Operating height | mm | 19152 |
| Operating width | mm | 4100 |
| Transport height | mm | 3321 |
| Transport width | mm | 3100 |
| Transport length | mm | 13230 |
| Total weight | t | 49 |
FAQ
1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is a year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
2: Why should you buy from us not from other suppliers?
TYSIM is the only one focused on the development civil for small and medium-sized enterprise, which is specialized in the rotary drilling rig and obtains more than 40 pile driving products patent. TYSIM core team is instituted by the senior researchers.
3: What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,AUD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Cash;
Language:Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
4: How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment
